Band Saw

Order Number: 5 6041 0010
The hydraulic band saw for pipes up to 180 mm diameter.
Energy source: Hydraulic
Energy source: Hydraulic
Operating pressure: 90-140 bar
Operating pressure: 90-140 bar
Cutting capacity: 7
Cutting capacity: 7"x7" (180 mm x 180 mm)
ATEX: II2GExhIIBT6Gb
ATEX: II2GExhIIBT6Gb

Technical Data

ORDER NO. 5 6041 0010
ATEX Specification II2GExhIIBT6Gb
Energy source Hydraulic
Operating pressure 90-140 bar
Volume flow 12-50 l/min
Power 1.5 kW
Free surface speed 76 m/min
Cutting capacity max. dia. 180.00 mm
Cutting capacity max. □ 180x180 (7“x7“) mm
Total length 730.00 mm
Height incl. motor 270.00 mm
Width 285.00 mm
Connection M18x1.5 mm
Hydraulic hose connection Flat-Star A250-OM/OF-1/2”BSP
Hydraulic medium Hydraulic oil
Flüssigkeitsumlauf open circuit
Oil filtration class ISO-level of purity 20/18/13
Temperature of oil -34 up to +82 °C
Viscosity of oil >13 centistokes
Noise level LpA 81.7 dB(A)
Noise level LwA 92.7 dB(A)
Vibration level 2.7 m/s²
Weight 13.5 kg
Fields of application / branch Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction

Accessories

ORDER NO. Teeth per inch
9 2506 0450 6/10
9 2506 0200 8
9 2506 0240 8/12
9 2506 0230 10/14
9 2506 0220 14
ORDER NO. For cutting
5 6031 9400 Pipes
5 6031 9500 Underground roof supports
ORDER NO. Description
2 1317 9010 Hydraulic hose set
9 9902 0120 Multi oil for cleaning and protection
