Circular Saw

Order Number: 5 1128 0010
The hydraulic circular saw for universal use, as well for underwater use.
Energy source: Hydraulic
Energy source: Hydraulic
Operating pressure: 140 bar
Operating pressure: 140 bar
Cutting depth 90°/45°: 60.0 mm/35.0 mm
Cutting depth 90°/45°: 60.0 mm/35.0 mm
Underwater operation
Underwater operation
ATEX: II2GExhIIBT5Gb
ATEX: II2GExhIIBT5Gb

Technical Data

ORDER NO. 5 1128 0010
ATEX Specification II2GExhIIBT5Gb
Energy source Hydraulic
Operating pressure 140 Bar
Volume flow 20 l/min
Power 2.3
Max. saw blade dia. 180.00 mm
Speed (free) 3.200 rpm
Cutting depth at 90°/45° 60.0/35.0 mm
Center dia. for saw blade 16.0/19.0/20.0/30.0 mm
Connection SAE Port No. 8 (3/4x16UNF-2B) mm
Hydraulic hose connection Flat-Star A250-OM/OF-1/2”BSP
Hydraulic medium Hydraulic oil
Hydraulic circuit type open circuit
Oil filtration class ISO-level of purity 20/18/13
Temperature of oil -34 bis +82 °C
Viscosity of oil >13 centistokes
Noise level LpA 85.0 dB(A)
Noise level LWA 96,0 dB(A)
Vibration level <2.5 m/s²
Weight 10.2 kg
Fields of application / branch Energy and pipeline construction; Metal industry and steel construction; Plant and mechanical construction; Underwater Work

Accessories

ORDER NO. Diameter Center dia. Number of teeth Cutting width Material thickness < 5 mm Material thickness 5-10 mm Material thickness > 10 mm Material
9 2503 0120 180.00 30.00 36 1.,85 x x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0230 180.00 20.00 48 2.00 x x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0240 180.00 20.00 48 1.60 x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0110 230.00 25.40 48 2,00 x x Steel, stainless steel, copper
9 2503 0160 230.00 25.40 60 2.00 x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0170 230.00 25.40 68 2.00 x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0180 230.00 25.40 84 2.00 x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0190* 230.00 25,40 48 2.00 x x Steel, stainless steel, copper
9 2503 0140 320.00 25.40 84 2.20 x x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
9 2503 0150* 320.00 25.40 84 2.20 x x x Plastics, plexiglass, aluminium, steel, stainless steel, copper
*coated (for longer lifetime)
ORDER NO. Description
9 9902 0120 Multi oil for cleaning and protection
